Head
Seidentopf Trinocular Head inclined at 25°, Erect image
Interpupillary Range 54mm-76mm with CTV adaptor
Eyepiece
Pair of PL10X/22 , FN22mm wide-field high eye-point Plan eyepiece
Objective
Quintuple nosepiece with Long working distance Infinity Plan Achromatic BD objective, with DIC slot.

5X(NA0.15)WD 11.0mm,
10X(NA0.30)WD 9.5mm,
20X(NA0.45)WD 3.4mm,
50X(NA0.55)WD 7.5mm,
100X(NA0.8)WD 2.1mm
Focus
Coaxial focus system with tension adjustable, Coarse focusing scope is 33mm with coarse adjustment stop and tightness adjustment, fine adjustment precision: 0.001 mm.
Stage
8” Three layer Mechanical Stage with coaxial drive control and clutch hand can move quickly move range 210x210mm stage size 525x330mm
glass stage
Observation method
Bright field / Dark field / Polarizing / DIC (option)
Illumination
90V-240V wide-range of Voltage,
Reflection: 12V/100W halogen adjustable illuminator with field diaphragm, aperture diaphragm.
Option
Transmitted illuminator system: single 5W LED, white, brightness adjustable, NA 0.5 condenser, with iris diaphragm, 4” stage, DIC prism
