Performance capabilities:
Support Flip & Freeze image,1/2
freeze image for comparison
Support to create Line&Mark generator
-12 groups movable cross hair,
horizontal line, vertical line
- create 3 groups of movable circle mark&size
- 360° circle scale
- 2 adjustable angle lines
- movable screen ruler & scale adjustable
- arrow mark
Measurement
- Calibration support and 5 groups memorized
- Linear distance,
- Circle diameter ,circumference and area
- Rectangular length, width, perimeter and area
- Polygon’s perimeter and area
- Circle Center distance
- Ellipse’s perimeter and area
- Arc’s radian and length
- Angle

1/3” CMOS color sensor
2M pixel progressive scan Resolution 1600x1200
1600x1200: 23 fps / 1680x1050: 26.5fps
1440x900 : 28 fps / 1366x768 : 29 fps
1280x1024: 25 fps / 1024x768 : 23 fps / 800x600 : 23 fps
Exposure control : Auto / Manual
White Balance : Auto / Manual
Color : Color, B/W, Sepia, Negative
Monitor interface : VGA
Storage : support USB disk 256M-32G
PS/2 Mouse control
Power 5V DC 100-240V power supply
