Biological Microscope Model E5



Head
30°Monoc, Seidentopf Binocular/Trinocular Head with 1/2 CTV
Eyepiece
PL10x/18 with/without reticle, pointer
Objective
Reversed quadruple nosepiece with
achromatic objective 4x,10x,40xs,100xs (Oil)
Stage
Mechanical Stage with coaxial drive control
Size: 132mm X 140mm, move range 76x50 mm
Illuminator
3W LED illuminator center presetting, intensity
adjustable, N.A 1.25 Abbe condenser with iris
diaphragm, 100-240V AC50/60Hz
Option
3W LED internal rechargeable batteries,
Plan achromatic objective, 20x objective
