Product Features

• Long working distance Infinity achromatic color corrected optical system
• Precision mechanical structure and ergonomic design
• New super bright single high-power 5W LED for reflect light
• With the Long working distance infinite plan achromatic objective
• 4” stage suitable for use of wafer or FPD inspection.
• Various function selections for observation, bright field, oblique, polarization, DIC differential interference contrast.

Application: industrial inspection and metallurgical analysis.

Head
Seidentopf Trinocular Head inclined at 30°,
Interpupillary Range 54mm-76mm with CTV adaptor
Eyepiece
Pair of PL10X/22 , FN22mm wide-field high eye-point Plan eyepiece
Objective
Quintuple nosepiece with Long working distance Infinity Plan Achromatic objective, with DIC slot.
5X(NA0.15)WD 10.8mm,
10X(NA0.30)WD 10mm,
20X(NA0.45)WD 4.0mm,
50X(NA0.55)WD 7.8mm,
100X(NA0.8)WD 2.1mm
Focus
Coaxial focus system with tension adjustable, Coarse focusing scope is 33mm with coarse adjustment stop and tightness adjustment, fine adjustment precision: 0.001 mm.
Stage
4"Double layer Mechanical Stage with coaxial drive control
move range 105x105mm, with metal flat stage

Observation method
Bright field / Oblique illuminator / Polarizing / DIC (option)
Illumination
90V-240V wide-range of Voltage,
Reflection: single 5W LED illuminator with field diaphragm, aperture diaphragm.
Option
Transmitted illuminator system: single 5W LED, white, brightness adjustable, NA 0.5 condenser,
with iris diaphragm, 6”stage, Erect Trinocular head, DIC prism
